Content » Vol 92, Issue 4

Letter to the Editor

Isotopic Response of Graft Versus Host Disease Following Herpes Zoster Infection: Case Report and Review of the Literature

Tarun Mehra, Giesela Metzler, Jürgen Bauer, Martin Köberle and Claus Garbe

Department of Dermatology, University Hospital of Tübingen, Liebermeisterstraße 25, DE-72076 Tübingen, Germany. E-mail:

Accepted October 16, 2011.

Wolf’s isotopic response is the occurrence of an unrelated cutaneous disorder in an area of healed skin previously affected by another pathology (1, 2), the most frequent being granulomatous reactions followed by dysimmune reactions and malignancies (3). Cutaneous graft versus host disease (GVHD) presenting as an isotopic response is very rare. We describe here an unusual manifestation of the aforementioned disorder and review the literature on this topic.


A 69-year-old Caucasian man presented with erythematous and hyperpigmented scaly plaques, which were either sharply or vaguely demarcated. They were predominantly located in the dermatome T4, with similar lesions on the upper back, shoulders and neck outside of T4 (Fig. 1).


Fig. 1. Erythematous and hyperpigmented scaly plaques, either sharply or vaguely demarcated: (a) on the right side of the thorax, dermatome Th 4; (b) on the back, shoulders and neck; (c) on the chest, dermatome Th 4; and (d) on the upper back, outside of Th 4.

His medical history revealed a myelodysplastic syndrome type refractory anaemia with excess blasts (RAEB), for which he had received an allogeneic stem cell transplant with a human leukocyte antigen (HLA) mismatch in December 2007 and donor lymphocytes in May 2008. He had received GVHD prophylaxis, comprising 30 mg methotrexate on day 1 after transplantation, and 20 mg on days 3 and 6, in addition to tacrolimus, starting a day before transplantation at 3 mg/day and reduced by 0.5 mg approximately every 3 weeks, over a period of 18 weeks. He had not developed an acute GVHD. He had received prednisolone for autoimmune hepatitis and polymyalgia rheumatica until one month before the appearance of his skin lesions, the maximum daily dose administered being 50 mg, which had been gradually reduced to 2 mg. The patient had had herpes zoster in the right dermatome T4 approximately 8 months before he presented at our department, which had been treated with ibuprofen 600 mg 3 times a day, tramadol 50 mg once daily and topically with fusidic acid gauze as an infection prophylaxis. As he had presented himself 10 days after the onset of symptoms, no aciclovir had been given. Due to persistent post-herpetic neuralgia, gabapentin 600 mg 3 times daily had been prescribed. He had been free of skin lesions for approximately 30 months after receiving allogeneic bone marrow transplantation (BMT).

Two 4-mm skin punch biopsies were taken, one from the upper back outside of T4 and another from the affected skin within T4.

Dermatohistopathological analysis revealed a superficial interface-dermatitis with hypergranulosis, orthohyperkeratosis and pigment incontinence, a complete loss of the epidermal stratum basale, as well as subepidermal detachment. A sparse and lymphocytic inflammatory infiltrate with a few eosinophilic granulocytes was present, but remained confined to the superficial dermis (Fig. 2). Dermatohistopathological differential diagnosis was a lichenoid drug eruption or a chronic GVHD. The sparse inflammatory infiltrate in the dermo-epidermal junction zone was unusual for a lichen planus or for a lichenoid drug reaction and the few eosinophils also did not strengthen the case for the latter diagnosis.


Fig. 2. Two skin biopsies taken from the upper back, (a) outside the area previously affected by herpes zoster and (b) from the area affected by herpes zoster. Superficial interface dermatitis with a lymphocytic infiltrate and pigment incontinence. In (a), complete loss of the stratum basale and décollement of the epidermis (arrow), hypergranulosis and orthohyperkeratosis. Infiltrate with eosinophilic granulocytes in the dermo-epidermal junction zone. In comparison, in (b), sparse lymphocytic infiltrate in the dermo-epidermal junction zone (arrowhead) with a vacuolar degeneration of the basement membrane. (a) Haematoxylin and eosin (H&E) ×200, (b) H&E ×100.

PCR did not detect varicella zoster virus (VZV)-DNA from a lesional skin sample. Serological testing with an enzyme-linked immunosorbent assay (ELISA) showed a borderline result for VZV IgM and a positive result for VZV IgG, compatible with a past VZV infection.

The patient was diagnosed with a post-herpetic isotopic response of GVHD following allogeneic stem cell transplantation, due to the consecution of skin lesions as well as dermatohistopathology. Topical therapy with triclosan 1% and betamethasone 0.2% in a petrolatum-based ointment was initiated and the patient was referred to private practice for further medical supervision.


Infection with VZV or herpes simplex virus (HSV) is the most common predisposing skin disorder for an isotopic response (4).

Of all isotopic responses following a VZV/HSV infection, the secondary cutaneous pathology is, in most cases, a granulomatous reaction, with 60 cases recorded so far, followed by dysimmune reactions (45 cases), malignancies (32 cases), leukaemic or lymphomatous infiltrations (19 cases), infections (15 cases) or other various causes (23 cases), summarized in Table SI (available from: http: // (3–7). The most common granulomatous reaction is granuloma annulare (3) and the prevailing immunoreactive lesions are lichenoid reactions (3). A wide range of malignancies can present as isotopic responses, ranging from skin metastasis of primary breast cancer (8), through squamous cell carcinoma (1) to leukaemic infiltration (9) or lymphoma (10). The dominance of fungal and viral infections hints at deficient local cellular immunity, as hypothesized by Ruocco et al. (3). A multitude of other skin pathologies can present as isotopic responses, including comedones (11), Stevens-Johnson syndrome (12) and keloid (13).

GVHD is a common complication of allogeneic BMT. It develops due to a HLA mismatch between the donor and the recipient, when mature donor T cells transplanted with the graft recognize the recipient’s tissue as foreign and initiate an immunological response (14).

To date, seven cases of GVHD manifesting as a post-herpetic isotopic response have been described, as summarized in Table SII (available from: (15–19), as well as two cases following a dermatomal pattern, without a confirmed diagnosis of herpes zoster infection in the affected area (20). Three further linear GVHD reactions following Blaschko’s lines (21–24) and one case of GVHD occurring in the area of total lymphoid irradiation (25) have been published. All patients with a post-herpetic GVHD had received allogeneic bone marrow transplantation. Our case brings the total of published cases of patients having developed GVHD as a post-herpetic isotopic response to eight. Nevertheless, this patient is the first recorded case of GVHD developing as a post-herpetic isotopic response presenting a dermatomal and non-dermatomal pattern.

The authors declare no conflicts of interest.

REFERENCES (full list)

  • Wyburn-Mason R. Malignant change arising in tissues affected by herpes. Br Med J 1955; 2: 1106–1109.
  • Wolf R, Brenner S, Ruocco V, Filioli FG. Isotopic response. Int J Dermatol 1995; 34: 341–348.
  • Ruocco V, Brunetti G, Puca RV, Ruocco E. The immunocompromised district: a unifying concept for lymphoedematous, herpes-infected and otherwise damaged sites. J Eur Acad Dermatol Venereol 2009; 23: 1364–1373.
  • Ruocco V, Ruocco E, Ghersetich I, Bianchi B, Lotti T. Isotopic response after herpesvirus infection: an update. J Am Acad Dermatol 2002; 46: 90–94.
  • Lee JH, Kim HS, Kim HO, Park YM. A Case of post-zoster eosinophilic dermatosis. Ann Dermatol 2009; 21: 274–276.
  • Ghorpade A. Wolf’s isotopic response – lichen planus at the site of healed herpes zoster in an Indian woman. Int J Dermatol 2010; 49: 234–235.
  • Ghorpade A. Wolf’s isotopic response – furuncles at the site of healed herpes zoster n an Indian male. Int J Dermatol 2010; 49: 105–107.
  • Cecchi R, Brunetti L, Bartoli L, Pavesi M, Giomi A. Zosteriform skin metastases rom breast carcinoma in association with herpes zoster. Int J Dermatol 1998; 37: 476–477.
  • Anhalt AW, Forsey RR. Herpes zoster, leukaemia cutis and leukaemic infiltration of he lesions of herpes zoster. Can Med Assoc J 1956; 75: 750–751.
  • Aloi FG, Appino A, Puiatti P. Lymphoplasmocytoid lymphoma arising in herpes zoster scars. J Am Acad Dermatol 1990; 22: 130–131.
  • del Rio E, Nova A, Allegue F, Fachal C, Veiga HA, Penaranda JM. Comedones appearing after herpes zoster infection: a report of 7 cases. Arch Dermatol 1997; 133: 1316–1317.
  • Tenea D. Carbamazepine-induced Stevens-Johnson syndrome sparing the skin previously affected by herpes zoster infection in a patient with systemic lupus erythematosus: a reverse isotopic phenomenon. Case Rep Dermatol 2010; 2: 140–145.
  • Requena L, Kutzner H, Escalonilla P, Ortiz S, Schaller J, Rohwedder A. Cutaneous reactions at sites of herpes zoster scars: an expanded spectrum. Br J Dermatol 1998; 138: 161–168.
  • Rupec RA, Plewig G. Graft-versus-Host-Disease: Ein interdisziplinäres Problem aus der Sicht des Dermatologen. J Dtsch Dermatol Ges 2004; 2: 249–259.
  • Lacour JP, Sirvent N, Monpoux F, Perrin C, Castanet J, Michel G, et al. Dermatotmal chronic cutaneous graft-versus-host disease at the site of prior herpes zoster. Br J Dermatol 1999; 141: 587–589.
  • Cordoba S, Fraga J, Bartolome B, Garcia-Diez A, Fernandez-Herrera J. Giant cell lichenoid dermatitis within herpes zoster scars in a bone marrow recipient. J Cutan Pathol 2000; 27: 255–257.
  • Sanli H, Anadolu R, Arat M, Ekmekci P, Birol A, Erdem C, et al. Dermatomal lichenoid graft-versus-host disease within herpes zoster scars. Int J Dermatol 2003; 42: 562–564.
  • Kawano N, Gondo H, Kamimura T, Aoki K, Iino T, Ishikawa F, et al. Chronic graft-versus-host disease following varicella-zoster virus infection in allogeneic stem cell transplant recipients. Int J Hematol 2003; 78: 370–373.
  • Baselga E, Drolet BA, Segura AD, Leonardi CL, Esterly NB. Dermatomal lichenoid chronic graft-vs-host disease following varicella-zoster infection despite absence of viral genome. J Cutan Pathol 1996; 23: 576–581.
  • Freemer CS, Farmer ER, Corio RL, Altomonte VL, Wagner JE, Vogelsang GB, et al. Lichenoid chronic graft-vs-host disease occurring in a dermatomal distribution. Arch Dermatol 1994; 130: 70–72.
  • Beers B, Kalish RS, Kaye VN, Dahl MV. Unilateral linear lichenoid eruption after bone marrow transplantation: an unmasking of tolerance to an abnormal keratinocyte clone? J Am Acad Dermatol 1993; 28: 888–892.
  • Kikuchi Y, Matsuyama A, Nomura K. Zosteriform metastatic skin cancer: report of three cases and review of the literature. Dermatology 2001; 202: 336–338.
  • Wilson BB, Lockman DW. Linear lichenoid graft-vs-host disease. Arch Dermatol 1994; 130: 1206–1208.
  • Cohen PR, Hymes SR. Linear and dermatomal cutaneous graft-versus-host disease. South Med J 1994; 87: 758–761.
  • Okamoto S, Takahashi S, Inoue T, Tojo A, Tani K, Kikuchi A, et al. Cutaneous chronic graft-versus-host disease localized to the field of total lymphoid irradiation. Bone Marrow Transplant 1996; 17: 111–113.
  • Gibney MD, Nahass GT, Leonardi CL. Cutaneous reactions following herpes zoster infections: report of three cases and a review of the literature. Br J Dermatol 1996; 134: 504–509.
  • Ruocco E, Baroni A, Cutri FT, Filioli FG. Granuloma annulare in a site of healed herpes zoster: Wolf’s isotopic response. J Eur Acad Dermatol Venereol 2003; 17: 686–688.
  • Sanli HE, Kocyigit P, Arica E, Kurtyuksel M, Heper AO, Ozcan M. Granuloma annulare on herpes zoster scars in a Hodgkin’s disease patient following autologous peripheral stem cell transplantation. J Eur Acad Dermatol Venereol 2006; 20: 314–317.
  • Watanabe D, Kuhara T, Ishida N, Tamada Y, Matsumoto Y. Sarcoid tissue reaction on herpes zoster scars in a myelodysplastic syndrome patient: Wolf’s isotopic response. J Eur Acad Dermatol Venereol 2009; 23: 475–477.
  • Watanabe T, Yoshida Y, Yamamoto O. Papules on the nape. Postherpetic granuloma annulare-like reaction (Wolf isotopic response). Arch Dermatol 2009; 145: 589–594.
  • Fernandez-Redondo V, Amrouni B, Varela E, Toribio J. Granulomatous folliculitis at sites of herpes zoster scars: Wolf’s isotopic response. J Eur Acad Dermatol Venereol 2002; 16: 628–630.
  • Schena D, Barba A, Chieregato C. Granulomatous folliculitis as a manifestation of post-herpetic isotopic response. J Eur Acad Dermatol Venereol 2001; 15: 473–475.
  • Snow JL, el-Azhary RA, Gibson LE, Estes SA, Espy MJ, Smith TF. Granulomatous vasculitis associated with herpes virus: a persistent, painful, postherpetic papular eruption. Mayo Clin Proc 1997; 72: 851–853.
  • Gutzmer R, Kiehl P, Hausmann M, Kapp A, Weiss J. Postzosterische Granulome mit Nachweis von Varizella-zoster-Virus-DNA in den Granulomen. Hautarzt 2001; 52: 1111–1114.
  • Ezra N, Ahdout J, Haley JC, Chiu MW. Granuloma annulare in a zoster scar of a patient with multiple myeloma. Cutis 2011; 87: 240–244.
  • De Somer L, Wouters C, Morren MA, De Vos R, Van Den Oord J, Devriendt K, et al. Granulomatous skin lesions complicating Varicella infection in a patient with Rothmund-Thomson syndrome and immune deficiency: case report. Orphanet J Rare Dis 2010; 5: 37.
  • Ladoyanni E, Rajpar S, Rodriguo T, Snead D, Ahmed I. An eruption after herpes zoster infection. Granulomatous reaction within atrophic VZV scars. Clin Exp Dermatol 2010; 35: 331–332.
  • Araki E, Kambe N, Takahashi K, Miyachi Y, Utani A. Multiple dermatomal daughter lesions of postzoster granuloma. Br J Dermatol 2007; 156: 1369–1371.
  • Chang SE, Bae GY, Moon KC, Do SH, Lim YJ. Subcutaneous granuloma annulare following herpes zoster. Int J Dermatol 2004; 43: 298–299.
  • Bell HK, King CM. An isotopic response to patch testing. Contact Dermatitis 2003; 49: 171–172.
  • Kim M-B, Jwa S-W, Ko H-C, Kim S-J, Kwon K-S, Oh C-K. A case of secondary cutaneous mucinosis following herpes zoster: Wolf’s isotopic response. Int J Dermatol 2009; 48: 212–214.
  • Zalaudek I, Leinweber B, Richtig E, Smolle J, Hofmann-Wellenhof R. Cutaneous zosteriform melanoma metastases arising after herpes zoster infection: a case report and review of the literature. Melanoma Res 2003; 13: 635–639.
