Content » Vol 93, Issue 1

Letter to the Editor

A Case of Almost Unilateral Focal Dermal Hypoplasia Resulting From a Novel Mutation in the Gene

Masayuki Asano1, Taku Fujimura1*, Chihiro Wakusawa1, Yoko Aoki2, Yoichi Matsubara2 and Setsuya Aiba1

Departments of 1Dermatology, and 2Medical Genetics, Tohoku University Graduate School of Medicine, Seiryo-machi 1-1, Aoba-ku, Sendai, 980-8574, Japan. *E-mail:

Accepted April 11, 2012.

Focal dermal hypoplasia (FDH), also known as Goltz syndrome, is an X-linked dominant disorder of ecto-mesenchymal development. In general, FDH presents with characteristic linear streaks of hypoplastic dermis and various abnormalities in some organs (1). Although this disorder is normally lethal in male patients, approximately 10% of cases of FDH are male, and most represent post-zygotic mosaicism (2–4).

The molecular basis of FDH involves mutations in the PORCN (human porcupine locus MG61/PORC) gene (5). PORCN is a member of the porcupine (porc) gene family and is located on chromosome Xp11. 23 (1, 6). The gene is thought to encode an O-acyltransferase that catalyses cysteine N-palmitoylation and serine O-acylation in the endoplasmic reticulum that allows membrane targeting and secretion of several Wnt proteins that have key roles in embryonic tissue development, notably for fibroblast proliferation and osteogenesis (1, 7).

We describe here a case of FDH with a novel deletion mutation at exon 14 (c.1179_1193 del) detected by PCR-sequencing analysis of the entire coding sequences of the PORCN gene. Interestingly, in this case, the characteristic symptom was prominent in the patient’s left hemibody. To the best of our knowledge, this is the second case report that reveals a mutation of the PORCN gene in a patient with almost unilateral FDH.


A 2-year-old Japanese girl visited our outpatient clinic for hypopigmented and atrophic linear skin lesions on the trunk and extremities. She had been surgically treated one year before for syndactyly of the left middle and ring finger. On her first visit to our hospital, physical examination disclosed hypo-pigmented patches of dermal hypoplasia distributed along Blaschko’s lines on the arms, legs and trunk (Fig. 1). Interestingly, these symptoms in lesions were prominent on her left hemibody. Her hair was sparse and brittle and she had non-scarring alopecia. In addition, extensive dental caries was noted. From the above information, we diagnosed this patient as having almost unilateral FDH.


Fig. 1. Skin manifestation in the patient. (A) Hair loss on the left temporal scalp. (B, C) Small whitish depigmented spots, slightly depressed from the skin surface, distributed linearly on the left side of the armpit (B) buttocks and lower limbs (C).

To confirm the diagnosis, we examined the PORCN gene for mutations. After receiving informed consent, DNA was extracted from the peripheral blood sample taken from affected individual using standard methods. Primers were designed to amplify individual exons and the flanking intron of the PORCN gene, as described previously (1). PCR-sequencing analysis of the entire coding sequences of PORCN revealed c.1179_1193 del mutation at exon 14 (Fig. 2). This variant was predicted to result in altered residues 394–412 and to produce a truncated protein (p.G394 fs X20). The sequence chromatograms showed low signal intensities at the site of mutation, indicating post-zygotic mutation. To verify the mosaic state, the PCR products were cloned into the pCR4 TOPO TA Cloning Vector (Invitrogen, Karlsruhe, Germany), transfected. E. coli clones were chosen and subjected to colony PCR, and PCR products from individual clones were sequenced. By DNA sequence analysis of selected clones we could assign the wild-type and the mutant sequence to either of the 2 banding patterns and identified a ratio of 5/26 (~19%; mutant vs. wild-type sequence).

Fig. 2. Molecular basis of focal dermal hypoplasia (FDH). (a) Sequencing of exon 14 of the PORCN gene in the patient’s DNA reveals c.1179_1193 del mutation. (b) Sequencing of control DNA shows the wild-type and mutant sequences.



FDH is characterized by linear and whorled lesions of hypoplastic dermis and variable abnormalities of organs including the bone, nails, hair, limbs and teeth (1–3). Cutaneous features that predominate at birth are red atrophic, linear lesions following Blaschko’s lines and telangiectasias. It is presumed to be lethal in men who are fully hemizygous for a mutation in PORCN (4). FDH generally involves both sides of the body. Only 6 cases of unilateral FDH have been published (8–10). Recently, Maalouf et al. (8) reviewed all cases of unilateral FDH and found no side predeliction. One case was male (17%) and the other 5 were females (83%). Moreover, they described that gene sequence analysis on the PORCN gene detected a novel heterogeneous mutation in exon 10, c.854-855insACCTGAC [p.T285fsX316]. In addition, a substantial majority of cases of FDH have previously been reported to result from post-zygotic mutations (11). In the present case, sequencing analysis of the entire coding sequences of PORCN gene revealed a novel deletion mutation at exon 14 (c.1179_1193 del). As a ratio of 5/26 mutant vs. wild-type alleles was found, a post-zygotic mutation is the likely cause of the syndrome in our case. A germline mutation would have resulted in a 1:1 distribution of both alleles in functional X-chromosome-mosaicism as described previously by Bornholdt et al. (11). Although we did not perform the X-chromosome inactivation analysis using DNA extracted from the affected and non-affected skin, the present case suggests that the deletion mutation at exon 14 might be connected with the unilateral involvement of FDH. To confirm our hypothesis, further case reports and molecular studies of patients with unilateral FDH are necessary.


  • Clements SE, Wessagowit V, Lai-Cheong JE, Arita K, McGrath JA. Focal dermal hypoplasia resulting from a new nonsense mutation, p.E300, in the PORCN gene. J Dermatol Sci 2008; 49: 39–42.
  • Lasocki AL, Stark Z, Orchard D. A case of mosaic Goltz syndrome (focal dermal hypoplasia) in a male patient. Australas J Dermatol 2011; 52: 48–51.
  • Buchner SA, Itin P. Focal dermal hypoplasia syndrome in a male patient: report of a case and histologic and immunohistochemical studies. Arch Dermatol 1998; 128: 1078–1082.
  • Yoshihashi H, Ohki H, Torii C, Ishiko A, Kosaki K. Survival of a male mosaic for PORCN mutation with mild focal dermal hypoplasia phenotype. Pediatr Dermatol 2011; 28: 550–554.
  • Grzeschik KH, Bornholdt D, Oeffner F, König A, del Carmen Boente M, Enders H, et al. Deficiency of PORCN, a regulator of Wnt signaling, is associated with focal dermal hypoplasia. Nat Genet 2007; 39: 833–835.
  • Carcicasole A, Ferraro T, Rimland JM, Terstappen GC. Molecular cloning and initial characterization of the MG61/ PORC gene, the human homologue of the Drosophila segment polarity gene Porcupine. Gene 2002; 288: 147–157.
  • Hoffman K. A superfamily of membrane-bound O-acyltransferases with implications for wnt signaling. Trends Biochem Sci 2000; 25: 111–112.
  • Maalouf D, Mégarbané H, Chouery E, Nasr J, Badens C, Lacoste C, Grzeschik KH, Mégarbané A. A novel mutation in the PORCN gene underlying a case of almost unilateral focal dermal hypoplasia. Arch Dermatol 2012; 148: 85–88.
  • Aoyama M, Sawada H, Shintani Y, Isomura I, Morita A. Case of unilateral focal dermal hypoplasia (Goltz syndrome). J Dermatol 2008; 35: 33–35.
  • Tenkir A, Teshome S. Goltz syndrome (focal dermal hypoplasia) with unilateral ocular, cutaneous and skeletal features: case report. BMC Ophthalmol 2010; 10: 28.
  • Bornholdt D, Oeffner F, König A, Happle R, Alanay Y, Ascherman J, et al. PORCN mutations in focal dermal hypoplasia: coping with lethality. Hum Mutat 2009; 30: E618–628.
