Clinical Report

Atopic Diathesis in Hypohidrotic/anhidrotic Ectodermal Dysplasia

Hanako Koguchi-Yoshioka1, Mari Wataya-Kaneda1, Mizuki Yutani1, Hiroyuki Murota1, Hajime Nakano2, Daisuke Sawamura2 and Ichiro Katayama1

Departments of Dermatology, 1Course of Integrated Medicine, Graduate School of Medicine, Osaka University, Osaka, and 2Hirosaki University Graduate School of Medicine, Hirosaki, Japan

Recently, patients with hypohidrotic/anhidrotic ectodermal dysplasia (H/AED) have been reported to have a higher prevalence of symptoms suggestive of atopic disorders than the general population. To better understand atopic diathesis in H/AED, 6 cases of clinically or genetically diagnosed H/AED were examined. The following criteria were evaluated with patient consent: sweating, blood test results, histopathology and filaggrin staining. Five of 6 H/AED cases displayed atopic dermatitis-like manifestations, and 3 of these 5 cases experienced periorbital lesions. Sweat ducts were not histopathologically observed, and filaggrin staining was similar to normal subjects. Serum IgE was elevated in 2 of the 3 patients. H/AED patients tended to present with atopic dermatitis-like eruptions with characteristics potentially indicative of periorbital lesions. Atopic diathesis in H/AED appeared not to be associated with filaggrin. We could speculate that hypohidrosis or anhidrosis itself might impair skin barrier function and contribute to atopic diathesis. Key words: hypohidrotic/anhidrotic ectodermal dysplasia; hypohidrosis/anhidrosis; atopic dermatitis; periorbital eczema.

Accepted Sep 30, 2014; Epub ahead of print Oct 1, 2014

Acta Derm Venereol

Mari Wataya-Kaneda, MD, PhD, Department of Dermatology, Course of Integrated Medicine, Graduate School of Medicine, Osaka University, 2-2, Yamadaoka, Suita-shi, Osaka, 565-0871, Japan. E-mail:

Hypohidrotic/anhidrotic ectodermal dysplasia (H/AED) is a rare genodermatosis characterised by abnormal development of the sweat glands, teeth, and hair. Using questionnaires, Mark et al. (1) recently demonstrated that children with ED syndromes have higher prevalence of symptoms suggestive of atopic disorders than the general paediatric population. However, few reports have described the characteristics of H/AED skin lesions from a clinical perspective. Our aim was to clarify atopic diathesis, the tendency to develop one or more of the atopic diseases, in H/AED. We also evaluated filaggrin expression in the skin of patients with H/AED.



Six patients with H/AED at Osaka University Hospital were examined (5 men and 1 woman; median age 12.5, range 1–35) (Patient Nos. 1–5 were clinically diagnosed with H/AED based on the triad signs of H/AED, and patient No. 6 was genetically diagnosed via a causative gene mutation).

Measurement of sudomotor function

Sweating was evaluated in 2 cases via starch-iodide paper or the quantitative sudomotor axon reflex test (Q-SART). Starch-iodide paper was attached to the palm. Dark spots on the patient’s palm result from reaction between starch and iodide in the presence of water from the sweat droplets, and these spots were compared to those on a control. Q-SART was performed as previously described (2). Briefly, a 2 mA current was applied for 5 min together with 10% acetylcholine to determine axon reflex-mediated sweating responses during acetylcholine iontophoresis.


Four-mm punch biopsies were collected from anhidrotic areas of in 3 patients. Hematoxylin-eosin or immunoperoxidase staining of paraffin-embedded sections was performed. A monoclonal mouse anti-human filaggrin antibody (Santa Cruz Biotechnology, Santa Cruz, California, USA) was used at a 1:450 dilution. Antigen retrieval was performed by heating sections under pressure for 10 min in 10 mM sodium citrate buffer, pH 6.0. Filaggrin stained H/AED skin was compared with filaggrin-related atopic dermatitis specimens and normal skin samples.

Ethical issue

The genetic analysis was performed at Hirosaki University Faculty of Medicine under the approval of its ethics committee. Written informed consent from the participant (patient No. 6) was obtained at Osaka University Faculty of Medicine. We were permitted to use the database of the result of genetic analysis by the ethics committee of the Osaka University Faculty of Medicine.


The patients’ characteristics are detailed in Table I. Five of the 6 cases had skin lesions resembling AD, such as dry skin, recurring itchy erythema, lichenification, or hyperpigmentation (Fig. 1). These 5 cases met Hanifin & Rajka’s (3) diagnostic criteria for AD. Three of these 5 patients (patient Nos. 2 [Fig. 1a], 4, and 5 [Fig. 1b]), displayed recurring eczema on periorbital sites. Serum IgE levels were elevated in 2 of the 3 patients having a blood test (patient Nos. 2–4) (normal range: < 300 IU/ml) (4). Two patients had a positive family history of allergic disorders, including AD, asthma, or hay fever. Starch-iodide paper sweat test results demonstrated minimal sweating responses (Fig. 2a) compared with the normal control (Fig. 2b). For patient No. 6, the Q-SART measurement results were 0 mg/cm2 on the abdomen and 0.18 mg/cm2 on the palm. Q-SART allows us to quantitate the amount of sweating and distinguish between anhidrotic and hypohidrotic regions in the patient. Mutational analysis using genomic DNA extracted from blood leukocytes of patient No. 6 revealed a heterozygous c.157insA mutation in the EDARADD gene, one of the causative genes of H/AED. Skin biopsies from anhidrotic areas of 3 patients (patient Nos. 1, 4, 6) showed normal epidermis but no sweat ducts in the dermis or subcutaneous adipose tissue (Fig. 3a, b). Immunohistochemical anti-filaggrin staining of patient skin specimens (Fig. 3a, b, lower parts) showed comparable staining to the normal control (Fig. 3d); staining was not reduced, unlike in filaggrin-related AD specimens (Fig. 3c).

Table I. Patients’ characteristics

Pat. No.





Skin lesions

Other clinical signs

Evaluation of sweating


Serum IgE (IU/ml)

Family history

Genetic mutation






Dry skin

Erythema on the cheeks


No sweat ducts (Fig. 3a)


Mother and a maternal uncle with AD







Pigmentation on the periorbital sites (Fig. 1a)











Eczema on the cubital (Fig. 1c) and popliteal regions

Starch-iodide paper (Fig. 2)



Mother with hypohidrosis and hay fever

A brother and a sister with asthma







Eczema on the whole body


No sweat duct (Fig. 3b)


A maternal uncle with H/AED

N/A (x-linked s/o)






Lichenification especially on the periorbital sites (Fig. 1b)

Short stature




A maternal uncle with H/AED

N/A (x-linked s/o)





No sweat ducts


Father with H/AED


N/A, not available; AD: atopic dermatitis; H/AED: hypohidrotic/anhidrotic ectodermal dysplasia; +: feature present; –: within normal clinical limits; s/o: suspect of.


Fig. 1. (a) Patient 2 presented with hyperpigmentation at periorbital sites. (b) Patient 5 experienced lichenification and pigmentation on periorbital regions. (c) Patient 3 displayed recurring itchy erythema on the cubital fossa. A written permission is given to publish this figures.


Fig. 2. Starch-iodide paper test; dark spots on the patient’s palm (a) resulting from the reaction between starch and iodide in the presence of water from sweat droplets were markedly reduced compared with the control (b).


Fig. 3. No sweat ducts were histopathologically observed in an anhidrotic area of patient 1 (a) and 4 (b). Filaggrin staining in patient 1 (a, lower part) and 4 (b, lower part) was similar to that of the normal control (d). Staining was not reduced unlike the staining of filaggrin-related atopic dermatitis specimen (c).


Similar to previous reports (1, 5), our H/AED cases frequently suffered from skin lesions that resembled AD. Three of 5 patients with AD-like eczema experienced eruptions at periorbital sites. According to Feser et al., (6) the following are significant risk factors for periorbital eczema; female, atopic skin diathesis and ≥ 40 years. Three patients with periorbital eczema were male and under 40 years of age; so in all the 3 risk factors which Feser et al. described, atopic skin diathesis was left. We could speculate that atopic diathesis in these H/AED patients might be attributed to periorbital dermatitis, which could be one of the characteristics of H/AED skin lesions.

Two of the 6 cases had a positive family history of allergic disorders, including AD, asthma, or hay fever. In addition, 2 of the 3 patients having a blood test displayed a high serum IgE level; Davis & Solomon (5) reported that IgE levels in patients with H/AED were higher than those of a control group, with a significance level of p = 0.01. Recent knowledge suggests that barrier dysfunction is the primary cause of AD and that increased IgE levels might be a secondary phenomenon (7). Speculatively, a defective skin barriers in patients with H/AED could be associated with increased IgE levels.

It is unclear, however, what causes the impaired skin barrier function in H/AED patients. Mutations in the gene-encoding filaggrin are a major genetic predisposing factor for AD (8). Angelova-Fischer et al. (9) demonstrated that the filaggrin mutation carriers had significantly reduced total and percentage amount of ceramide 4 compared with the wild-type. In addition, Jungersted et al. (10) reported similar ceramide profiles in H/AED and AD patients. However, our results suggest no association between H/AED and filaggrin although filaggrin status were not available for all the patients because some patients disagreed with several kinds of tests, or stopped follow-up visit.

Impaired sweating was recently implicated as a cause of barrier dysfunction in AD (2, 11). Various reports indicate reduced sweating responses in AD patients compared with non-atopic controls (2, 11, 12). It is also reported that patients with AD have reduced amount of dermcidin in sweat, which is one of the human antimicrobial peptides secreted into sweat (13). This might contribute to the high susceptibility of AD patients to skin infections and to altered bacterial skin colonisation. Although filaggrin data were not reported in these studies, it could be said that most of these AD cases exhibiting defective sweating were unrelated to filaggrin, taking into the frequency of filaggrin mutation account (for example, the percentage of Japanese AD patients with filaggrin mutation is about 25% (14)). In addition, Watabe et al. (15) demonstrated that among natural moisturising factors, the levels of lactate, urea, sodium, and potassium were significantly lower in anhidrotic areas of patients with acquired idiopathic generalised anhidrosis or segmental anhidrosis than in adjacent hidrotic areas. They concluded that these factors in sweat played a crucial role in maintaing the hydration state of stratum corneum.

H/AED is a rare genetic disease, so it is difficult to statistically prove that reduced sweat production is underlying cause for atopic eczema, but taking the above findings together, we could predict that hypohidrosis/anhidrosis itself might contribute to impaired barrier function, resulting in AD diathesis and secondarily to elevated IgE levels in patients with H/AED.

Consistent with previous reports, our H/AED patients tended to present with skin manifestations that were indistinguishable from AD. Our clinical evaluation indicated that periorbital dermatitis could be characteristics of H/AED skin lesions. H/AED appears to be not associated with filaggrin. In addition, it could be speculated that hypohidrosis or anhidrosis itself might impair the skin barrier and contribute to atopic diathesis in H/AED.

The authors declare no conflict of interest.


1. Mark BJ, Becker BA, Halloran DR, Bree AF, Sindwani R, Fete MD, et al. Prevalence of atopic disorders and immunodeficiency in patients with ectodermal dysplasia syndromes. Ann Allergy Asthma Immunol 2012; 108: 435–438.

2. Kijima A, Murota H, Matsui S, Takahashi A, Kimura A, Kitaba S, et al. Abnormal axon reflex-mediated sweating correlates with high state of anxiety in atopic dermatitis. Allergol Int 2012; 61: 469–473.

3. Hanifin JM, Rajka G. Diagnostic features of atopic dermatitis. Acta Derm Venereol 1980; Suppl. 92: 44–47.

4. Kuwana M. IgE. J Jpn Med Assoc 2006; 135: S149.

5. Davis JR, Solomon LM. Cellular immunodeficiency in anhidrotic ectodermal dysplasia. Acta Derm Venereol 1976; 56: 115–120.

6. Feser A, Plaza T, Vogelgsang L, Mahler V. Periorbital dermatitis – a recalcitrant disease: causes and differential diagnoses. Br J Dermatol 2008; 159: 858–863.

7. Kabashima K. New concept of the pathogenesis of atopic dermatitis: interplay among the barrier, allergy, and pruritus as a trinity. J Dermatol Sci 2013; 70: 3–11.

8. Palmer CN, Irvine AD, Terron-Kwiatkowski A, Zhao Y, Liao H, Lee SP, et al. Common loss-of-function variants of the epidermal barrier protein filaggrin are a major predisposing factor for atopic dermatitis. Nat Genet 2006; 38: 441–446.

9. Angelova-Fischer I, Mannheimer AC, Hinder A, Ruether A, Franke A, Neubert RH, et al. Distinct barrier integrity phenotypes in filaggrin-related atopic eczema following sequential tape stripping and lipid profiling. Exp Dermatol 2011; 20: 351–356.

10. Jungersted JM, Hogh JK, Hellgren LI, Agner T, Jemec GB. Ceramide profile in hypohidrotic ectodermal dysplasia. Clin Exp Dermatol 2012; 37: 153–155.

11. Eishi K, Lee JB, Bae SJ, Takenaka M, Katayama I. Impaired sweating function in adult atopic dermatitis: results of the quantitative sudomotor axon reflex test. Br J Dermatol 2002; 147: 683–688.

12. Shiohara T, Doi T, Hayakawa J. Defective sweating responses in atopic dermatitis. Curr Probl Dermatol 2011; 41: 68–79.

13. Paulmann M, Arnold T, Linke D, Ozdirekcan S, Kopp A, Gutsmann T, et al. Structure-activity analysis of the dermcidin-derived peptide DCD-1L, an anionic antimicrobial peptide present in human sweat. J Biol Chem 2012; 287: 8434–8443.

14. Nomura T, Akiyama M, Sandilands A, Nemoto-Hasebe I, Sakai K, Nagasaki A, et al. Prevalent and rare mutations in the gene encoding filaggrin in Japanese patients with ichthyosis vulgaris and atopic dermatitis. J Invest Dermatol 2009; 129: 1302–1305.

15. Watabe A, Sugawara T, Kikuchi K, Yamasaki K, Sakai S, Aiba S. Sweat constitutes several natural moisturizing factors, lactate, urea, sodium, and potassium. J Dermatol Sci 2013; 72: 177–182.
